    PEB Structure Fabrication Services

    What our PEB structure fabrication services cover

    Civoool’s PEB structure fabrication services turn your approved engineering drawings into finished steel members, ready for site erection. In our Lahore facility, raw plate and coil are cut, built into tapered I-sections, drilled for bolted connections, welded, cleaned, and coated under one roof.

    Fabricating in a controlled factory rather than on an open site means tighter tolerances, faster assembly, and fewer surprises when the frame reaches your plot. Every primary member, purlin, and bracing piece is match-marked to the erection drawings before it leaves the floor.

    Why does the quality of the Workshop affect the site speed?

    The quality of the steel that leaves our Workshop decides how the build goes on site. When holes line up, members are straight, and connections fit the first time, a crew can bolt a frame together in days. Poor fabrication shows up as field rework: redrilling, flame cutting, and delays that no schedule can absorb. We fix it where correction is cheapest, on the shop floor.

    Fabrication scope at a glance:
    • Built-up Tapered Columns
    • CNC Cutting and Drilling
    • Code-Based Welding
    • Blast Cleaning and Paint
    Our fabrication scope covers the full primary and secondary steelwork of a pre-engineered building. We form tapered built-up columns and rafters from plate, punch connection holes on CNC lines for accuracy, and weld them in accordance with recognized structural codes. Members are then blast cleaned and coated to suit your site, from a dry inland plant to a humid coastal warehouse.

    Our PEB Fabrication Process, Step By Step

    Fabrication at Civoool follows a fixed sequence, so quality is built in at every stage. First, incoming steel is checked against mill certificates and the bill of materials, because a frame is only as sound as the plate it starts from. Plates are cut, then web and flange pieces are assembled into built-up columns and rafters.

    Welders join them under qualified procedures, and each member is checked for straightness, dimension, and weld quality. Surface preparation is followed by blast cleaning, then the agreed primer and finish coat go on. Finally, every piece is match-marked and loaded in sequence for dispatch.

    What Sets Our Steel Apart

    01

    Accurate Fit-Up

    CNC-driven cutting and drilling keep holes and cleats aligned, so bolting on site stays fast and clean.

    02

    Reliable Welds

    Welds follow qualified procedures and are checked for quality, ensuring the joints your frame relies on are protected.

    03

    Durable Coatings

    Surface prep and coating are matched to your climate, resisting Pakistan's heat, humidity and salt air.

    Materials and standards we fabricate to

    Good fabrication starts with the right material and a clear rulebook. We work with structural steel grades suited to PEB primary and secondary framing, and we fabricate built-up sections, hot-rolled members, and cold-formed purlins and girts to match the approved design.

    Steel grades and sections

    Primary frames are usually built-up plate sections, sized by your engineer for the spans and loads of your building. Secondary members, such as Z and C purlins, are cold-formed for strength at low weight, keeping your steel tonnage and cost sensible. Base plates and anchor-bolt settings are fabricated to the same drawings, so each frame seats correctly on your foundation.

    Welding and tolerances

    Welding follows recognised structural welding practice, and finished members are checked against fabrication tolerances for length, camber, and hole position. Maintaining these tolerances on the floor allows an erection crew to assemble your frame quickly and safely once the steel arrives at the project site.

    Why Choose Civoool For PEB Fabrication?

    Single-Source Fabrication

    Cutting, welding, surface preparation, and coating all take place in one facility, so quality is controlled at every stage, and your steel never passes through a chain of subcontractors with different standards.

    Climate-Ready Coatings

    Pakistan's climate runs from dry inland heat to humid, salty coastal air. We match surface preparation and paint systems to where your building will stand, so the coating protects your steel for years.

    Erection-Ready Accuracy

    Members are cut, drilled, and marked to fit together on site exactly as intended in the drawings. That removes most field cutting and redrilling, the two issues that most often stall a steel erection and add cost.

    Traceable Material Control

    Incoming steel is checked against mill certificates and the bill of materials before fabrication starts. That link between document and member means the steel in your finished frame is the steel specified.

    Common fabrication pitfalls we prevent

    Most problems on a steel project are born in the fabrication shop, not on site, and knowing where they come from is half the battle in preventing them. A little care on the floor saves days during erection, so each fault below is one we actively check for before steel leaves the shop.

    Weld distortion

    Built-up sections are made by welding plates together, which introduces heat into the steel. Without controlled fit-up and a planned welding sequence, columns and rafters can twist or bow. We manage heat input and sequence so members stay within camber and sweep limits, which matters when many frames must line up across a long building.

    Misplaced holes

    A connection hole drilled a few millimetres out is invisible in the shop and a serious problem on site. CNC cutting and drilling from the same approved model keep hole positions consistent across matching members, so bracing, cleats, and connections meet exactly as drawn.

    Coating failures

    Paint applied over poorly prepared or damp steel peels early, and in a humid or coastal Pakistani setting, it fails faster still. Proper blast cleaning to the specified standard, the right primer, and correct film thickness are what make a coating last, rather than simply look finished on dispatch day.

    Marking and fit

    Steel that arrives unmarked turns erection into guesswork. Every member we ship is match-marked to the erection drawings and grouped by frame, so your crew can identify and place each piece in the right order without hunting through a stack of look-alike sections.
    Testimonial

    What Clients Say About Us

    FAQs

    PEB structure fabrication is the factory stage at which approved engineering drawings are turned into finished steel members. Plates are cut, built into columns and rafters, welded, drilled, cleaned, and coated, then marked for assembly. It sits between design and on-site erection in a pre-engineered building project.

    Fabrication time depends on the building's size, tonnage, and complexity, not a fixed figure. A small warehouse frame is fabricated faster than a large multi-bay plant. Once your design and material are confirmed, we can give a realistic shop schedule for your specific structure rather than a generic promise.

    Yes. We fabricate in Lahore and dispatch finished, match-marked steel to project sites across Pakistan. Members are loaded in the erection sequence and protected for transport, so your site team receives steel ready to assemble wherever your plant or warehouse is being built.

    We fabricate secondary members in accordance with recognised structural steel and welding practices, with finished members checked against fabrication tolerances. Your project engineer specifies the steel grades and section sizes, and we fabricate to that approved design rather than substituting material on our own.

    Coating is matched to your site. After blast cleaning, we apply the agreed primer and finish system, choosing protection that suits dry inland heat or humid, salty coastal air. The right surface preparation and film thickness matter more than the paint name for how long a coating lasts.
